The PEY instant water heater features all the standard functions you would expect from an electronically controlled device. The rotary selector allows you to quickly set your desired temperature through the analog temperature scale.
Extremely Convenient - Incredibly Good
The PEY instant water heater features all the standard functions you would expect from an electronically controlled device. The rotary selector allows you to quickly set your desired temperature through the analog temperature scale.
Perfect shower experience
With electronic control, the water temperature is continuously monitored. This eliminates temperature fluctuations and water preheating time. Additionally, it ensures precise water temperature up to maximum performance, turning the shower into an enjoyable experience - every time.
Product Details
- Electronically controlled instant water heater for sink, kitchen sink, shower, or bathtub supply.
- Quick control type (Close Loop).
- Variable temperature selection (from 30°C to 60°C) using an analog scale.
- Suitable for operation with solar input temperatures up to 45°C.
- Built-in diagnostic system, electronic air detector.
- Heat exchanger made of glass fiber reinforced polyamide.
- 4 internal indirect spiral resistances immersed directly in water.
- Accurate flow rate measurement.
- Connection options for both central or local use.
- Suitable for connection with VPE plastic pipes with DVGW test mark.
- Easy installation thanks to the separate mounting plate and twist lock, with installation standard, front panel removal from the front, without screws, electrical connection from above or below.
- Powered by permanent connection.
- Can be connected to all commercially available taps.
Benefits for Your Home
- Electronic control with output sensor for higher comfort level.
- Precise water temperature up to maximum performance.
- High energy efficiency - 30% savings.
- Quick temperature selection from 30°C to 60°C.
- Built-in diagnostic system.
- "Bare wire" technology electric resistances for trouble-free operation even with hard water.
- Suitable for use with preheated water up to 45°C (e.g., from solar).
What is an instant water heater?
The instant water heater is a type of water heater that heats water in real-time. It only heats the water that passes through it at that moment. There is no hot water storage tank. This has many advantages, such as energy savings, since only the water that is used is heated, and longer lifespan, as there is no water tank and no accumulation of salts on the resistance and other components.
It operates with electricity and is three-phase, meaning a three-phase power supply is required.
How It Works
The instant water heater has a cold water inlet pipe, which passes through the resistance, heats up, and exits through the hot water outlet pipe. A necessary condition for the instant water heater to initially operate is the pressure of the cold water inlet should not be too low.
The water temperature is regulated by a thermostat, so it does not exceed a maximum value. The temperatures reached by the hot water are pre-set so that one can use the hot water directly, without needing to mix it with cold water.
The maximum temperature that can be reached for hot water production is 60 °C, while the maximum water flow rate reaches up to 12.6 liters per minute. Indicatively, 38-42 °C degrees are standard for shower use.
Advantages of instant water heaters compared to traditional electric water heaters
- It is small in size and does not take up much space.
- There are no energy losses, as only the water being used at that moment is heated. Therefore, we save on the electricity bill. In a traditional water heater, the hot water that is not used goes to waste.
- The hot water used in the instant water heater is used as is, without mixing with cold, as happens in a traditional water heater. Thus, we also save water, in addition to electricity.
- There is no need to wait for the water to heat up. As soon as we turn on the tap, hot water flows in a few seconds. The traditional water heater takes a few minutes, depending on its size.
- The hot water never runs out. As long as we have the tap open, we will have hot water.
Product Guides
- Product Number
- SE092001
Product Details
- Power Source
- Three-phase electric
- Maximum Power
- 24 kW
- Maximum Flow Rate
- 12.6 lt/min
- Maximum Temperature
- 60 °C
- Temperature Setting
- Heating Levels
- Placement
- Central Installation
- Wall Mounted
- Yes
- Inverter
- No
- Remote Control
- No
Dimensions
- Height
- 48.5 cm
- Width
- 22.6 cm
- Length
- 9.3 cm
