Description
Specifications
The Alantec single-mode SM 1J 9/125 optical pigtail, category G.657.A1, features an LC/APC connector and is 2 m long. It is designed for telecommunications networks, LAN, WAN, CCTV and FTTx installations.
- Fiber type: single-mode 9/125 µm, ITUT-G G.657A1
- Number of fibers: 1J
- Connector: LC/APC
- Ferrule material: ceramic
- Length: 2 m
- Minimum bend radius: ≥10 mm
- Insertion loss (IL): typical 0.25 dB, maximum 0.50 dB
- Return loss (RL): ≥ 45 dB
- Outer sheath: LSZH / FRNC, EASY STRIP
- Maximum cable outer diameter: 1.0 mm
- Operating temperature: -40°C to +70°C
- Packaging: 12 pieces
- Type
- -
- Category
- -
- Length
- 2 m
- Outdoor
- -
- Colour
- -
- Terminated
- -
- Flat
- -
- Fiber Optic Connectors
- -
