The InLine KVM & Data Switch is a KVM over IP transmitter with HDMI 1.4, USB and Gigabit Ethernet. It transmits Full HD, USB and IR signals over an Ethernet network and supports resolutions up to 1920 × 1200 at 60 Hz. It can be connected directly to a receiver or through a switch, and one transmitter can serve multiple receivers.

• Type: KVM over IP
• Connections: HDMI 1.4, USB 1.1, 1 × RJ45 Gigabit Ethernet
• Resolution: 1920 × 1200 at 60 Hz
• Video bandwidth: 6.75 Gb/s
• Colour spaces: RGB, YCbCr 444, YCbCr 422
• Colour depth: 8 / 10 / 12 bit
• HDMI audio: LPCM 2.0, 32 / 44.1 / 48 kHz
• IR frequency: 20–60 kHz
• Housing: Metal
• Colour: Black
• Dimensions: 9.2 × 6.7 × 2 cm
• Power supply: AC 100–240 V / 50–60 Hz, DC 5 V / 1 A
• Maximum power consumption: 5 W
• Operating temperature: −10 to +50 °C
• Storage temperature: −20 to +60 °C
• Operating humidity: 20–90%, non-condensing
• Package contents: Transmitter, 1.5 m IR transmitter cable, power supply and manual in German and English
