Deepcool AK700 Digital Nyx CPU Cooler for Socket 1851 AM5 1700

Top next-generation cooling power, 7 copper heat pipes, automatic dust cleaning, and AI algorithm for completely silent operation!

See full description

Description

Description

The DeepCool AK700 DIGITAL NYX redefines the category of high-performance single-tower air coolers. Equipped with advanced Core Touch (CTT 2.0) technology, 7 copper heat pipes, an enhanced 4-segment digital display, and an intelligent DeepCreative AI management system, it offers top-tier thermal dissipation for the most demanding processors on the market.

  • Smart 4-Segment Digital Display: Monitor in real-time the temperature, usage (%), power consumption (Watt), and frequency (GHz) of your processor. It only requires an internal USB 2.0 port on the motherboard.

  • AI-Tuned Cooling (DeepCreative Interface): The built-in AI algorithm monitors the CPU load and automatically adjusts the fan curve without needing to tweak the BIOS. If the temperature exceeds 80 °C, the fans instantly ramp up to 100% for immediate cooling.

  • 7 Copper Heatpipes & CTT 2.0: Precision copper base with 7 heatpipes (Ø6 mm) and an improved matrix fin array for maximum heat transfer.

  • 0-RPM & Activate Clearing (ACT) Technologies:

    • 0-RPM Mode: The fan remains completely stationary under low load (<5% PWM) for absolute silence.

    • ACT (Auto Dust Clearing): When the computer starts, the fan spins in reverse for 8 seconds, expelling dust from the blades and radiator!

  • Premium Offset Design for RAM: Heatpipes with a special offset angle that leave the space above the RAM slots completely free, allowing the installation of RAM with tall heat spreaders.

  • Wide Compatibility: Full support for the latest Intel sockets (LGA 1851, LGA 1700, LGA 1200, LGA 115x) and AMD (AM5, AM4).

Technical Specifications:

  • Manufacturer / Model: DeepCool AK700 DIGITAL NYX (Black)
  • Cooling Type: High-End CPU Air Cooler (Single-Tower)
  • Intel Compatibility: LGA 1851, LGA 1700, LGA 1200, LGA 1156, LGA 1155, LGA 1151, LGA 1150
  • AMD Compatibility: AM5, AM4
  • Heatpipes: 7x Ø6 mm Direct-Contact Copper Heatpipes
  • Fan Dimensions: 120 x 120 x 25 mm
  • Fan Bearing Type: Hydro Bearing (3-Phase, 6-Slot, 4-Pole Motor)
  • Fan Speed (RPM): 0 - 2700 ± 10% RPM (4-pin PWM)
  • Airflow: 77.23 CFM
  • Static Pressure: 5.13 mmAq
  • Noise Level: 21.0 / 28.8 / 36.0 dBA
  • Display Area: 29 x 39 mm (4-Segment Quad Display)
  • Display Connection: Internal USB 2.0 Header (5V DC / 0.65 W)
  • Radiator Dimensions: 124 x 76 x 151 mm
  • Total Dimensions (L x W x H): 126 x 98 x 157 mm
  • Net Weight: 1252 g

Manufacturer

See full description

Specifications

Specifications

Main Specifications

Type
Active
Socket
1851, AM5, 1700
Dual Fan
No
Colour
Black

Technical Specifications

Thermal Design Power (TDP)
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The DeepCool AK700 DIGITAL NYX redefines the category of high-performance single-tower air coolers. Equipped with advanced Core Touch (CTT 2.0) technology, 7 copper heat pipes, an enhanced 4-segment digital display, and an intelligent DeepCreative AI management system, it offers top-tier thermal dissipation for the most demanding processors on the market.

  • Smart 4-Segment Digital Display: Monitor in real-time the temperature, usage (%), power consumption (Watt), and frequency (GHz) of your processor. It only requires an internal USB 2.0 port on the motherboard.

  • AI-Tuned Cooling (DeepCreative Interface): The built-in AI algorithm monitors the CPU load and automatically adjusts the fan curve without needing to tweak the BIOS. If the temperature exceeds 80 °C, the fans instantly ramp up to 100% for immediate cooling.

  • 7 Copper Heatpipes & CTT 2.0: Precision copper base with 7 heatpipes (Ø6 mm) and an improved matrix fin array for maximum heat transfer.

  • 0-RPM & Activate Clearing (ACT) Technologies:

    • 0-RPM Mode: The fan remains completely stationary under low load (<5% PWM) for absolute silence.

    • ACT (Auto Dust Clearing): When the computer starts, the fan spins in reverse for 8 seconds, expelling dust from the blades and radiator!

  • Premium Offset Design for RAM: Heatpipes with a special offset angle that leave the space above the RAM slots completely free, allowing the installation of RAM with tall heat spreaders.

  • Wide Compatibility: Full support for the latest Intel sockets (LGA 1851, LGA 1700, LGA 1200, LGA 115x) and AMD (AM5, AM4).

Technical Specifications:

  • Manufacturer / Model: DeepCool AK700 DIGITAL NYX (Black)
  • Cooling Type: High-End CPU Air Cooler (Single-Tower)
  • Intel Compatibility: LGA 1851, LGA 1700, LGA 1200, LGA 1156, LGA 1155, LGA 1151, LGA 1150
  • AMD Compatibility: AM5, AM4
  • Heatpipes: 7x Ø6 mm Direct-Contact Copper Heatpipes
  • Fan Dimensions: 120 x 120 x 25 mm
  • Fan Bearing Type: Hydro Bearing (3-Phase, 6-Slot, 4-Pole Motor)
  • Fan Speed (RPM): 0 - 2700 ± 10% RPM (4-pin PWM)
  • Airflow: 77.23 CFM
  • Static Pressure: 5.13 mmAq
  • Noise Level: 21.0 / 28.8 / 36.0 dBA
  • Display Area: 29 x 39 mm (4-Segment Quad Display)
  • Display Connection: Internal USB 2.0 Header (5V DC / 0.65 W)
  • Radiator Dimensions: 124 x 76 x 151 mm
  • Total Dimensions (L x W x H): 126 x 98 x 157 mm
  • Net Weight: 1252 g

Manufacturer

Main Specifications

Type
Active
Socket
1851, AM5, 1700
Dual Fan
No
Colour
Black

Technical Specifications

Thermal Design Power (TDP)
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

104,02 €
14,00 €   shipping cost
