Technical Details

• Power Supply: Voltage: AC100-240V, 50/60Hz
• Control:
  • Control Functions: DMX512, Manual mode
  • DMX Channels: 384 channels
  • Scene Storage: 30 banks, 8 scenes per bank (total 240 scenes)
  • Chase Programs: 6 chase banks with up to 240 steps each
  • Fade Time Control: Adjustable via dedicated fader
  • Speed Control: Adjustable via dedicated fader
  • Blackout Function: Immediate blackout control button
  • Tap Sync and Auto Mode: Available for flexible scene activation
  • MIDI Compatibility: Supports MIDI signal input for remote control
• Features:
  • Lighting Control: Supports up to 12 intelligent fixtures, each with 16 DMX channels
  • Programmed Scenes: Allows saving and recalling lighting sequences
  • Joystick Control: For precise pan/tilt movement adjustment
  • LCD Display: Backlit screen for easy navigation and setting adjustment
  • Assignable Faders: 16 faders for direct control of lighting functions
  • Master & Slave Mode: Synchronization with multiple controllers
• Operating Environment:
  • Operating Temperature: Maximum 40°C
  • Cooling System: Passive cooling (no built-in fan)
  • Indoor Use Only: Not waterproof, avoid moisture exposure
• IP Rating: IP20 (Indoor use only)
