Digital IQ Electric Car Three-phase Charging Station Cable 8m Type 2 - Type 2 CB16A03-8
Electric Car Charging Station Cables

Digital IQ Electric Car Three-phase Charging Station Cable 8m Type 2 - Type 2 CB16A03-8

Charging Cable for electric and plug-in vehicles with silver-plated pins.

  • Ergonomic design with a comfortable grip for easy installation and removal.
  • Supports vehicle electronic lock functions.

Charging Cable for electric and plug-in vehicles with silver-plated pins.

  • Ergonomic design with a comfortable grip for easy installation and removal.
  • Supports vehicle electronic lock functions.
  • Compatible with all fully electric and hybrid Type 2 vehicles (IEC62196).
See full description See full description
Review the product
Product report

Description

Description

Charging Cable for electric and plug-in vehicles with silver-plated pins.

  • Ergonomic design with a comfortable grip for easy installation and removal.
  • Supports vehicle electronic lock functions.
  • Compatible with all fully electric and hybrid Type 2 vehicles (IEC62196).

Technical Specifications:

  • Maximum Provided Charging Power: 11kW
  • Maximum Current: 16A
  • Phases: 3
  • Cable Length: 8m
  • Certifications: CE / FCC / RoHS / UL
  • Voltage Resistance: 2000V
  • Voltage: 220V - 380V AC
  • Operating Temperature: -30℃ to 50℃
  • Fire Safety Rating: UL94V-0

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Phase Capacity
Three-phase
Cable Length
8 m
Connection Type
Type 2 - Type 2

Connection Type

  • Type 2: Compatible with all new electric vehicles available in the EU. Maximum charging power of 22kW (43kW at fast charging stations).
  • Type 1: Single-phase plug with a charging power of up to 7.4kW mainly for countries outside the EU.
  • Schuko: The classic plug for household sockets with a maximum charging power of up to 3.7kW.
Maximum Charge Power
11 kW

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

Charging Cable for electric and plug-in vehicles with silver-plated pins.

  • Ergonomic design with a comfortable grip for easy installation and removal.
  • Supports vehicle electronic lock functions.
  • Compatible with all fully electric and hybrid Type 2 vehicles (IEC62196).

Technical Specifications:

  • Maximum Provided Charging Power: 11kW
  • Maximum Current: 16A
  • Phases: 3
  • Cable Length: 8m
  • Certifications: CE / FCC / RoHS / UL
  • Voltage Resistance: 2000V
  • Voltage: 220V - 380V AC
  • Operating Temperature: -30℃ to 50℃
  • Fire Safety Rating: UL94V-0

Manufacturer

Manufacturer Details

Warnings & Safety Information
Phase Capacity
Three-phase
Cable Length
8 m
Connection Type
Type 2 - Type 2

Connection Type

  • Type 2: Compatible with all new electric vehicles available in the EU. Maximum charging power of 22kW (43kW at fast charging stations).
  • Type 1: Single-phase plug with a charging power of up to 7.4kW mainly for countries outside the EU.
  • Schuko: The classic plug for household sockets with a maximum charging power of up to 3.7kW.
Maximum Charge Power
11 kW

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
