Pedrollo UPm 4/5-GE Single-phase Water Pump 1.5hp 48SP2150A1U
Submersible Water Pumps

Pedrollo UPm 4/5-GE Single-phase Water Pump 1.5hp 48SP2150A1U

Key features:

  • Maximum submersion depth: 20m
  • Maximum temperature: 40°C
  • Outlet: 1 1/4
  • Power: 1100W
See full description

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Voltage

    Single-Phase

    Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

  • Manometric Height

    67

    The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

    • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
    • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
  • See all
Product report

Description

Description

Submersible well pump from the manufacturer Pedrollo, used for pumping clean water from tanks, flooded basements, or for pumping rainwater that does not contain particles.

Main feature is that the impellers do not stick even after long periods of inactivity, thanks to new innovative design techniques. With a high degree of efficiency, suitable for domestic, urban, and agricultural applications, such as water distribution, pressure systems for garden irrigation, etc.

Characteristics

  • Independent floating impellers. Double mechanical seal in an oil bath.
  • More compact in size (-20%). With reduced energy consumption.
  • Minimum pumping level of 135mm from the bottom edge of the pump.
  • With an integrated 20-meter cable certified for drinking water.
  • Maximum liquid temperature +40 0C. Maximum diving depth 20 meters.
  • With the suction grid raised to prevent the suction of sand, leaves & other particles.
  • Vertical or horizontal installation with the use of an optional kit.
  • Body material: Stainless steel AISI 304
  • Impeller material: Plastic (NORYL)

Pumped liquid

  • Clean, without solid particles and abrasive substances, not viscous, not corrosive, without crystals,
  • Chemically neutral, with characteristics like water.
  • Maximum sand content 150gr/m3

Technical specifications

Submersible motor, two-pole, asynchronous with external cooling from the pumped liquid. Protection IPX8, insulation class F.

Stator in a sealed AISI304 shell. Single-phase motors have built-in thermal protection in the winding.

Three-phase motors must be protected with external thermal protection.

  • Power: 1.5 HP
  • Voltage: 230V/ 50HZ
  • Outlet: 1 1/4''
  • With built-in float switch

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
Well, Rainwater

Type

Well
They are designed to pump water from underground sources when the water is at a depth, and are mainly used for water supply, irrigation, and other applications in areas that do not have easy access to surface water.
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Voltage
Single-Phase

Voltage

Single-Phase

Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.
Horsepower
1.5 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
1125 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.
Cable Length
10 m

Features

with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
Yes

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Outlet Nozzle
1 1/4"

Outlet Nozzle

The outlet nozzle refers to the point or the external diameter of the pump from which the pumped water or liquid exits. It is an important feature for determining the connection of the pump with the piping system and affects the flow capacity of the liquid.
Vortex
No

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Maximum Head Height
67 m

Maximum Head Height: 67


The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

  • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
  • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
Maximum Output
7.2 m³/h

Maximum Output

The maximum output or flow of a submersible water pump, as defined by the manufacturers, is the maximum amount of water the pump can move under ideal conditions, usually with zero head (i.e., no lift resistance).
Pump Submersion Depth
20 m

Materials & Construction

Set
No
Stainless
Yes

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
