Satel Wireless RF Curtain Motion Sensor Infrared 92° Detection Angle Scope 18m
Motion Sensors

Satel Wireless RF Curtain Motion Sensor Infrared 92° Detection Angle Scope 18m

MPD-310 motion sensor that detects movement in a protected area. Supported by: PERFECT alarm panels (WRL models), VERSA-MCU controller, MTX-300 controller, and MICRA alarm module (software version...

MPD-310 motion sensor that detects movement in a protected area. Supported by: PERFECT alarm panels (WRL models), VERSA-MCU controller, MTX-300 controller, and MICRA alarm module (software version 2.02 or newer required).

  • Motion detection with passive infrared sensor (PIR)
  • Viewing angle with maximum detectable area of 18x16.5 m
  • Ability to use curtain lens...
See full description See full description

  • Connectivity

    Refers to the wireless communication protocol used by the sensor to connect with other alarm systems or devices.

  • Login

    Wireless

    It connects wirelessly via a wireless communication protocol to the installation system. It is powered by a battery.

  • Detection Type

    Infrared

    Detects motion by sensing changes in infrared radiation (heat) emitted by humans or animals.

  • Range

    The range refers to the maximum distance in meters within which it can detect motion.

  • Detection Angle

    The width of the area that a sensor can cover to detect motion. The more degrees, the larger the coverage field.

  • Curtain

    With a narrow detection angle that allows monitoring of a specific area (windows, doors, narrow passages) and prevents false alarms from surrounding movement.

    1

  • Mounting Height

    The recommended maximum installation height of the sensor.
  • See all
Review the product
Product report

Description

Description

MPD-310 motion sensor that detects movement in a protected area. Supported by: PERFECT alarm panels (WRL models), VERSA-MCU controller, MTX-300 controller, and MICRA alarm module (software version 2.02 or newer required).

  • Motion detection with passive infrared sensor (PIR)
  • Viewing angle with maximum detectable area of 18x16.5 m
  • Ability to use curtain lens (in CT-CL coverage) or long-range (in LR-CL coverage)
  • Digital motion detection algorithm
  • Digital temperature compensation
  • Activation/deactivation of approach zone controls
  • Encrypted radio transmissions at 433 MHz frequency
  • LED indicators for signaling
  • Traffic detection system
  • Battery check
  • Protection against tampering when opening the case and from detachment from the ground

Product Information:

  • Type: Motion Sensor
  • Range: 600 m
  • Power supply: CR123A battery
  • Required environmental conditions: Class according to EN50130-5: II
  • Operating temperature range: -10°C...+55°C
  • Maximum humidity rate: 93 (+/-3%)
  • Color: White
  • Dimensions: 62 x 137 x 42 mm
  • Weight: 147 g
  • Expected battery life (energy saving, years): up to 3 years
  • Protection level according to EN 50131-2-2 (direct wall mounting): Grade 2
  • Detection area (highest sensitivity): 18 m x 16.5 m, 92°
  • Detection area (normal sensitivity): 14 m x 11.5 m, 82°
  • Wireless communication range (open field) for MRU-300: up to 250 [m]
  • Wireless communication range (open field) for MICRA / VERSA-MCU / MTX-30: up to 500 [m]
  • Wireless communication range (open field) for PERFECTA: up to 600 [m]
  • Startup time: 15 [s]
  • Supplementary standards: EN 50131-1, EN 50130-4, EN 50130-5
  • Detectable motion speed: 0.3...3 [m/s]
  • Standby current consumption: 45 [µA]
  • Operating frequency range: 433.05 ÷ 434.79 [MHz]
  • Maximum current consumption: 48 [mA]
  • Recommended installation height: 2.4 [m]

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Detection Type
Infrared

Detection Type

Infrared

Detects motion by sensing changes in infrared radiation (heat) emitted by humans or animals.
Detection Angle
92 °

Detection Angle

The width of the area that a sensor can cover to detect motion. The more degrees, the larger the coverage field.
Scope
18 m

Scope

The range refers to the maximum distance in meters within which it can detect motion.
Mounting Height
2.4

Mounting Height

The recommended maximum installation height of the sensor.
Connector
Wireless

Connector

Wireless

It connects wirelessly via a wireless communication protocol to the installation system. It is powered by a battery.
Battery
No

Battery

Powered by battery.

Additional Features

Antimasking
No

Antimasking

Function that detects any malicious interference, covering or blocking of the lens and automatically activates the alarm.
Tamper
Yes

Tamper

Refers to protection against attempts to tamper with the device. For example, if someone tries to open the sensor's casing or remove it from its position, the sensor will send an alarm signal.
Curtain
Yes

Curtain

With a narrow detection angle that allows monitoring of a specific area (windows, doors, narrow passages) and prevents false alarms from surrounding movement.
Placement
Wall
Recessed
No
PET
No

PET

Motion sensors with this technology are designed to "ignore" the movement of small animals, such as dogs and cats, thus preventing false alarms.
Built-in Camera
No

Smart Attributes

Connectivity
RF

Connectivity

Refers to the wireless communication protocol used by the sensor to connect with other alarm systems or devices.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

MPD-310 motion sensor that detects movement in a protected area. Supported by: PERFECT alarm panels (WRL models), VERSA-MCU controller, MTX-300 controller, and MICRA alarm module (software version 2.02 or newer required).

  • Motion detection with passive infrared sensor (PIR)
  • Viewing angle with maximum detectable area of 18x16.5 m
  • Ability to use curtain lens (in CT-CL coverage) or long-range (in LR-CL coverage)
  • Digital motion detection algorithm
  • Digital temperature compensation
  • Activation/deactivation of approach zone controls
  • Encrypted radio transmissions at 433 MHz frequency
  • LED indicators for signaling
  • Traffic detection system
  • Battery check
  • Protection against tampering when opening the case and from detachment from the ground

Product Information:

  • Type: Motion Sensor
  • Range: 600 m
  • Power supply: CR123A battery
  • Required environmental conditions: Class according to EN50130-5: II
  • Operating temperature range: -10°C...+55°C
  • Maximum humidity rate: 93 (+/-3%)
  • Color: White
  • Dimensions: 62 x 137 x 42 mm
  • Weight: 147 g
  • Expected battery life (energy saving, years): up to 3 years
  • Protection level according to EN 50131-2-2 (direct wall mounting): Grade 2
  • Detection area (highest sensitivity): 18 m x 16.5 m, 92°
  • Detection area (normal sensitivity): 14 m x 11.5 m, 82°
  • Wireless communication range (open field) for MRU-300: up to 250 [m]
  • Wireless communication range (open field) for MICRA / VERSA-MCU / MTX-30: up to 500 [m]
  • Wireless communication range (open field) for PERFECTA: up to 600 [m]
  • Startup time: 15 [s]
  • Supplementary standards: EN 50131-1, EN 50130-4, EN 50130-5
  • Detectable motion speed: 0.3...3 [m/s]
  • Standby current consumption: 45 [µA]
  • Operating frequency range: 433.05 ÷ 434.79 [MHz]
  • Maximum current consumption: 48 [mA]
  • Recommended installation height: 2.4 [m]

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Detection Type
Infrared

Detection Type

Infrared

Detects motion by sensing changes in infrared radiation (heat) emitted by humans or animals.
Detection Angle
92 °

Detection Angle

The width of the area that a sensor can cover to detect motion. The more degrees, the larger the coverage field.
Scope
18 m

Scope

The range refers to the maximum distance in meters within which it can detect motion.
Mounting Height
2.4

Mounting Height

The recommended maximum installation height of the sensor.
Connector
Wireless

Connector

Wireless

It connects wirelessly via a wireless communication protocol to the installation system. It is powered by a battery.
Battery
No

Battery

Powered by battery.

Additional Features

Antimasking
No

Antimasking

Function that detects any malicious interference, covering or blocking of the lens and automatically activates the alarm.
Tamper
Yes

Tamper

Refers to protection against attempts to tamper with the device. For example, if someone tries to open the sensor's casing or remove it from its position, the sensor will send an alarm signal.
Curtain
Yes

Curtain

With a narrow detection angle that allows monitoring of a specific area (windows, doors, narrow passages) and prevents false alarms from surrounding movement.
Placement
Wall
Recessed
No
PET
No

PET

Motion sensors with this technology are designed to "ignore" the movement of small animals, such as dogs and cats, thus preventing false alarms.
Built-in Camera
No

Smart Attributes

Connectivity
RF

Connectivity

Refers to the wireless communication protocol used by the sensor to connect with other alarm systems or devices.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
