Modular switch 3x18, surface-mounted, hermetic RH-54/3 (36.154).

The hermetic panels of the RH "NEO" series are designed for residential and industrial use, allowing the installation of surge protectors and electrical devices. They are available in a surface-mounted version and are widely used in outdoor installations.

• Distribution boards equipped with transparent, tinted doors that open to the side (left or right).
• Customized for the installation of a lock.
• Available in white, made from ABS material resistant to high temperatures up to 960°C.
• Operational stability from -25°C to +60°C.
• Impact resistance (IK rating 07).
• Capable of installing cameras with a depth of 68 and 75 mm.
• Models with 12 units and larger equipped with knockouts on the walls for cable entries and installation pipes.
• Doors can be sealed.
• Equipped with terminal strips for N and PE lines.
• TH 35 mounting base.
• Adhesive label for descriptions.

Technical specifications:

• Type: 3 x 18
• N+PE terminals: Yes
• Dimension A: 435 mm
• Dimension B: 580 mm
• Dimension C: 138 mm
• Surface installation
• IP rating: IP65
• Depth: 138 mm
• Height: 580 mm
• Width: 435 mm
