Technical specifications

• Design
• Mounting method: wall-mounted
• Functions
• With cable entry: yes
• Main electrical features
• Rated voltage: 400 V
• Cover, door
• Lock type: latch
• Protection degree IP with door: 30
• Locking capability: no
• Cover type: with pre-cut holes
• Door lock: none
• Door: single
• Transparent door: no
• Materials, finish, colors
• Color: white
• RAL color: RAL 9010 - Pure white
• Material: mixed materials
• Surface treatment type: galvanized
• Dimensions
• Installed product depth: 96.5 mm
• Internal depth: 92.5 mm
• Installed product height: 515 mm
• Length: 515 mm
• Installed product width: 305 mm
• Width in division units: 12
• Cabinet material thickness: 2.5 mm
• Installation, mounting
• Suitable for outdoor use: no
• Equipment
• Number of units: 12
• Number of rows: 3
• Number of rails in the panel: 1
• Accepts accessories: yes
• Expandable: yes
• Standards
• Glow Wire Tested, made of self-extinguishing material at: 750 °C
• European WEEE directive: applicable
• Protection class according to IEC-61140: II
• Safety
• Impact resistance IK: IK05
• Protection degree IP: IP30
• Protection class: insulation class II
• Halogen free: yes
• Impact resistance: IK05
• Operating conditions
• Operating temperature: -40…40 °C
