Steinel IS180-2 Wired Infrared Motion Sensor 180° Detection Angle Scope 12m
Motion Sensors

Steinel IS180-2 Wired Infrared Motion Sensor 180° Detection Angle Scope 12m

Infrared motion and twilight sensor IS 180-2 B with a range of 12m and maximum power supply of 1000W. It features a detection angle of 180° and IP54 protection.

The infrared wall sensor is excellently...

Infrared motion and twilight sensor IS 180-2 B with a range of 12m and maximum power supply of 1000W. It features a detection angle of 180° and IP54 protection.

The infrared wall sensor is excellently constructed from steel alloy, ideal for controlling large areas in front of the house, as well as indoor spaces such as corridors or basements. The IS 180-2...

See full description See full description

  • Login

    Wired

    It connects to the installation system via cable.

  • Detection Type

    Infrared

    Detects motion by sensing changes in infrared radiation (heat) emitted by humans or animals.

  • Range

    The range refers to the maximum distance in meters within which it can detect motion.

  • Detection Angle

    The width of the area that a sensor can cover to detect motion. The more degrees, the larger the coverage field.

  • Protection Certification

    IP54

    Suitable for indoor or outdoor areas with limited dust. Provides protection against the ingress of objects and withstands light rain or water splashes.

  • Mounting Height

    The recommended maximum installation height of the sensor.
  • See all
Product report

Description

Description

Infrared motion and twilight sensor IS 180-2 B with a range of 12m and maximum power supply of 1000W. It features a detection angle of 180° and IP54 protection.

The infrared wall sensor is excellently constructed from steel alloy, ideal for controlling large areas in front of the house, as well as indoor spaces such as corridors or basements. The IS 180-2 combines modern design with the latest detection technology.

  • Two high-sensitivity infrared detectors positioned at a special angle for effective control of large areas up to 200m².
  • Detection area adjustable up to 12m or 5m by rotating the multi-lens.
  • Lighting and twilight sensitivity adjustment via a regulator.
  • Easy and quick connection.

Technical specifications:

  • Dimensions (H x W x D): 120 x 76 x 56mm
  • Power supply: maximum 1000W (active load e.g. lamp)
  • Supply voltage: 230 - 240V, 50Hz
  • Detection angle: 180° with 90° opening angle
  • Twilight sensitivity adjustment: 2 - 2000Lux
  • Time setting: 10 sec. - 15 min.
  • Fixed lamp: adjustable (4 hours)
  • Protection rating: IP 54
  • Color: white
  • Equipment: includes corner wall mount.

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Detection Type
Infrared

Detection Type

Infrared

Detects motion by sensing changes in infrared radiation (heat) emitted by humans or animals.
Detection Angle
180 °

Detection Angle

The width of the area that a sensor can cover to detect motion. The more degrees, the larger the coverage field.
Protection Certification
IP54

Protection Certification

IP54

Suitable for indoor or outdoor areas with limited dust. Provides protection against the ingress of objects and withstands light rain or water splashes.
Scope
12 m

Scope

The range refers to the maximum distance in meters within which it can detect motion.
Mounting Height
2

Mounting Height

The recommended maximum installation height of the sensor.
Connector
Wired

Connector

Wired

It connects to the installation system via cable.
Battery
No

Battery

Powered by battery.

Additional Features

Antimasking
No

Antimasking

Function that detects any malicious interference, covering or blocking of the lens and automatically activates the alarm.
Tamper
No

Tamper

Refers to protection against attempts to tamper with the device. For example, if someone tries to open the sensor's casing or remove it from its position, the sensor will send an alarm signal.
Curtain
No

Curtain

With a narrow detection angle that allows monitoring of a specific area (windows, doors, narrow passages) and prevents false alarms from surrounding movement.
Placement
Wall
Recessed
No
PET
No

PET

Motion sensors with this technology are designed to "ignore" the movement of small animals, such as dogs and cats, thus preventing false alarms.
Built-in Camera
No

Smart Attributes

Connectivity
-

Connectivity

Refers to the wireless communication protocol used by the sensor to connect with other alarm systems or devices.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (1)

Reviews

5.0
1
5.0
Review this product
  1. 1
  2. 4 stars
    0
  3. 3 stars
    0
  4. 2 stars
    0
  5. 1 star
    0
Review this product

Description & Specifications

Infrared motion and twilight sensor IS 180-2 B with a range of 12m and maximum power supply of 1000W. It features a detection angle of 180° and IP54 protection.

The infrared wall sensor is excellently constructed from steel alloy, ideal for controlling large areas in front of the house, as well as indoor spaces such as corridors or basements. The IS 180-2 combines modern design with the latest detection technology.

  • Two high-sensitivity infrared detectors positioned at a special angle for effective control of large areas up to 200m².
  • Detection area adjustable up to 12m or 5m by rotating the multi-lens.
  • Lighting and twilight sensitivity adjustment via a regulator.
  • Easy and quick connection.

Technical specifications:

  • Dimensions (H x W x D): 120 x 76 x 56mm
  • Power supply: maximum 1000W (active load e.g. lamp)
  • Supply voltage: 230 - 240V, 50Hz
  • Detection angle: 180° with 90° opening angle
  • Twilight sensitivity adjustment: 2 - 2000Lux
  • Time setting: 10 sec. - 15 min.
  • Fixed lamp: adjustable (4 hours)
  • Protection rating: IP 54
  • Color: white
  • Equipment: includes corner wall mount.
