Management Features

• Switch Type: Managed
• Layer Switching: L2
• Quality of Service (QoS) Support: NO
• Internet Management: NO
• Command Line Interface (CLI) Configuration: NO
• Event Logging System: NO

Connectivity

• Number of Basic Switching Ethernet Ports: RJ-4644
• Type of Basic Switching Ethernet Ports: RJ-45 Gigabit Ethernet (10/100/1000)
• Number of Combo SFP Ports: 4
• Optical Channel Ports: 2
• Optical Fiber Slot: SFP

Networking

• Network Standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• 10G Support: NO
• Copper Network Cable Technology: 10BASE-TX, 1000BASE-T
• Port Mirroring: NO
• Flow Control Support: NO
• Link Aggregation: NO
• Broadcast Storm Control: NO
• Rate Limiting: NO
• Spanning Tree Protocol: NO
• VLAN Support: NO
• Virtual LAN Functions: Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN

Optical Fiber

• Optical Fiber Ethernet Cabling Technology: 1000BASE-X

Data Transfer

• Address Table Size: 16000 entries
• Routing/Switching Capacity: 100 Gbit/s
• Forwarding Rate: 74 Mpps
• Packet Buffer Memory: 1.5 MB

Security

• DHCP Functions: DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay
• Access Control List (ACL): NO
• IGMP Snooping: NO
• Security Algorithm Support: SNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS
• MAC Address Filtering: NO
• Authentication: Guest VLAN, MAC-based authentication
• Authentication Type: IEEE 802.1x, RADIUS

Multicast Functions

• Multicast Support: NO

Design

• Rack Mounting: NO
• Product Color: Black
• Certifications: ISV, LVD, BSMI, FCC 15 A, CE EMC A, BSMI ENC, RoHS A

Performance

• Internal Memory: 256 MB
• Flash Memory: 32 MB
• Noise Level: 49.5 dB
• Firmware Upgrade Capability: NO
• MTBF Rate: 466921 h

Power Management

• AC Input Voltage: 100 - 240 V
• AC Input Frequency: 50 - 60 Hz
• Power Consumption (max): 474.3 W
• Power over Ethernet (PoE) Technology: NO
• Number of Power over Ethernet (PoE) Ports: 48
• Total Power over Ethernet (PoE) Budget: 375 W

Environmental Conditions

• Operating Temperature Range: 0 - 50 °C
• Storage Temperature Limits: -40 - 70 °C
• Operating Humidity Range: 10 - 95%
• Non-operating Humidity: 10 - 95%
• Heat Dissipation: 1617.363 BTU/h

Weight and Dimensions

• Width: 441 mm
• Depth: 270 mm
• Height: 44 mm
• Weight: 4100 g

Package Contents

• Cables Included: AC
• Package Width: 616 mm
• Package Depth: 355 mm
• Package Height: 107 mm
• Package Weight: 5250 g

Logistics Data

• Harmonized System (HS) Code: 85176990
