Leo Group AJM90B Electric Surface Water Pump Centrifugal with Automatic Suction 1.5hp Single-Phase
Surface Water Pumps

Leo Group AJM90B Electric Surface Water Pump Centrifugal with Automatic Suction 1.5hp Single-Phase Code: 01014

Key features:

  • Horsepower: 1.5 HP
  • Maximum head: 48m
  • Maximum flow rate: 3.9 m³/h
  • Maximum operating pressure: 8 bar
  • Maximum suction depth: 9m
See full description

  • Power Supply

    Electric

    Ideal for continuous and demanding operation (e.g. for a flooded field and/or basement) 2. More economical consumption than gasoline-powered pumps 3. More environmentally friendly

  • Self-Priming

    The engine is automatically activated when the water in the tank falls below the lower limit. Similarly, it is deactivated when the tank is filled.

  • Centrifugal

    Pumps with impellers that enhance water flow.
  • Voltage Single-Phase

  • Flow rate

    The amount of water that the pump can provide. For example, 6m³/h is equivalent to 100 liters/minute.

  • Manometric Height

    This is the distance from the suction point to the maximum height that the water reaches (For example, for a height of 10 meters of water, a pressure of 1 bar is required).

  • Pressure

    The unit of measurement for the pressure exerted by the pump on the water (For example, for a height of 10 meters of water, a pressure of 1 bar is required).
  • See all
Product report

Description

Description

Centrifugal self-priming pump suitable for water or other liquids with similar physical and chemical properties to water. Ideal for household use, pressure systems, small agricultural applications, and irrigation.

  • Cast iron pump body with anti-corrosive protection
  • Impeller and shaft made of Inox
  • Maximum water temperature: +35°C
  • Maximum suction depth: 9m
  • Thermal protection
  • Insulation class: F
  • Protection class: IPX4
  • Power: 1.5 HP (1,100 watt)
  • Maximum head: 48m
  • Maximum flow rate: 3.9 m³/h
  • Voltage: 230V
  • Outlet sizes: 1’’
  • Maximum operating pressure: 8 bar
  • Temperature range: -10 to +40°C

Capabilities

Self-priming centrifugal pump suitable for water or other liquids with similar physical and chemical properties to water. Ideal for domestic use, pressure booster sets, small agricultural applications, and irrigation.

Features

  • Cast iron pump body with anti-corrosion protection
  • Impeller and shaft made of Inox
  • Maximum water temperature: +35°C
  • Maximum suction depth: 9m
  • Thermal protection
  • Insulation class: F
  • Protection class: IPX4
  • Capacity: 1.5 HP (1,100 watt)
  • Maximum head: 48m
  • Maximum flow rate: 3.9 m³/h
  • Voltage: 230V
  • Inlet/outlet size: 1’’
  • Maximum operating pressure: 8 bar
  • Temperature limits: -10 to +40°C

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
01014

Main Specifications

Power Source
Electric

Power Source

Electric
Ideal for continuous and demanding operation (e.g. for a flooded field and/or basement) 2. More economical consumption than gasoline-powered pumps 3. More environmentally friendly
Placement
Horizontal
Automatic Suction
Yes

Automatic Suction

The engine is automatically activated when the water in the tank falls below the lower limit. Similarly, it is deactivated when the tank is filled.
Centrifugal
Yes

Centrifugal

Pumps with impellers that enhance water flow.
Firefighting
No
Power Type
Single-Phase
Set
No

Technical Specifications

Horsepower
1.5 hp
Power
1100 W
Flow Rate
3.9 m³/h

Flow Rate

The amount of water that the pump can provide. For example, 6m³/h is equivalent to 100 liters/minute.
Manometric Head
48 m

Manometric Head

This is the distance from the suction point to the maximum height that the water reaches (For example, for a height of 10 meters of water, a pressure of 1 bar is required).
Pressure
8 bar

Pressure

The unit of measurement for the pressure exerted by the pump on the water (For example, for a height of 10 meters of water, a pressure of 1 bar is required).

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
