Wilo Rexa MINI3-V04.11/M06-523/A-5M Single-phase Pump Waste Water / Sewage 0.8hp 3094005
Submersible Water Pumps

Wilo Rexa MINI3-V04.11/M06-523/A-5M Single-phase Pump Waste Water / Sewage 0.8hp 3094005

Key features:

  • Maximum pump submersion: 2m
  • Cable length: 5m
  • Maximum temperature: 40 °C
  • Outlet: 2"
  • Performance: 22000Lit/h
See full description

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Voltage

    Single-Phase

    Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

  • Manometric Height

    11

    The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

    • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
    • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
  • See all

User Manual

440 00 €
Delivery Mon, 29 Jun - Wed, 01 Jul
41,00 €   shipping cost
Sent from Greece
From Aidinis Pumps Services
Greece
1 piece
See Water Pumps on the page of Aidinis Pumps Services
Product report

Description

Description

The Wilo-Rexa MINI3 pump is a suitable submersible sewage pump for the drainage of houses and construction sites. Its free passage of 40mm serves to transport dirty water and sewage-free waste. The versatile pump is suitable for both permanent and portable wet installation within a shaft. If the pump is placed in a DrainLift WS 50 drainage shaft, sewage with waste can be pumped, as the system has EN 12050-1 approval. The optimized hydraulic system offers high reliability for general application in different fluids. The pump can also be installed in narrow dirty water pits thanks to its compact design. The oil-filled sealing chamber and double sealing allow for longer maintenance intervals. Direct access to the most important components makes maintenance easy.

Features

  • Good performance grade and high level of operational safety, thanks to the optimized hydraulic system
  • Easy installation even in narrow pits with dirty water, thanks to the compact design, light weight, built-in capacitor, and screw flange
  • Reliable application in dirty water in different uses thanks to the corrosion-resistant impeller and cast cable gland
  • Longer maintenance intervals thanks to the large-volume sealing chamber and double sealing
  • Quick maintenance thanks to direct access to the sealing chamber and pump casing
  • The Wilo-Rexa MINI3 pump is the ideal, typical submersible sewage pump for the transfer of dirty water and sewage that does not contain waste according to DIN EN 12050-2, for the drainage of houses and construction sites.
  • The versatile pump is suitable for both stationary and portable wet installation within a pit.
  • The optimized hydraulic system offers high reliability for general application in different liquids.
  • The pump can also be installed in narrow pits with dirty water thanks to its compact design.
  • The oil-filled sealing chamber and double sealing allow for longer maintenance intervals.
  • Direct access to the most important components makes maintenance easy.
  • Specially designed Vortex impeller: Ø 40mm free passage of solids.

Specifications

  • Maximum pump immersion: 2m
  • Cable length: 5m
  • Maximum temperature: 40 °C
  • Nozzle: 2"
  • Performance: 22000Lit/h
  • Electrical connection: 1~230 V, 50 Hz or 3~400 V, 50 Hz
  • Operating mode "submersible": S1
  • Operating mode "emerging": S3 20%
  • Protection rating: IP68
  • Insulation class: F
  • Liquid temperature: 3 ... 40 °C (37 ... 104 °F)
  • Power: 600W
  • Head(max): 11 m
  • Particle size(max): 40 mm

Materials

  • Hydraulic system casing: EN-GJL-200 (ASTM A48 Class 30)
  • Impeller: Composite material (PK-GF30)
  • Suction port cover plate: Stainless steel
  • Motor housing: 1.4301 (AISI 304)
  • Sealing:
    • At the pump: C/MgSi (BXPFF)
    • On the motor side: NBR
    • Static: NBR
  • Shaft end: 1.4301 (AISI 304)

The package includes

  • Pump
  • Installation and operation instructions

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Guides

User Manual

Dimensions

Type
Waste Water / Sewage

Type

Waste Water / Sewage

Waste water / sewage pumps are used for pumping and transporting waste water, sewage, and other liquids containing solids or particles
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Voltage
Single-Phase

Voltage

Single-Phase

Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.
Horsepower
0.8 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
600 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.
Cable Length
5 m

Features

with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
Yes

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Outlet Nozzle
2"

Outlet Nozzle

The outlet nozzle refers to the point or the external diameter of the pump from which the pumped water or liquid exits. It is an important feature for determining the connection of the pump with the piping system and affects the flow capacity of the liquid.
Vortex
Yes

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Maximum Head Height
11 m

Maximum Head Height: 11


The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

  • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
  • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
Maximum Output
22 m³/h

Maximum Output

The maximum output or flow of a submersible water pump, as defined by the manufacturers, is the maximum amount of water the pump can move under ideal conditions, usually with zero head (i.e., no lift resistance).
Pump Submersion Depth
2 m
Maximum Particle Size
40 mm

Maximum Particle Size

Specifies the largest size of solid particles (such as sand, stones, or other impurities) that the device can pump without clogging or being damaged.

Materials & Construction

Set
No
Stainless
No
Protection Certification
IP68

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
