Online Usv-Systeme USV Xanto 1000R UPS On-Line 1000VA 1000W with 8 IEC Outlets
UPS

Online Usv-Systeme USV Xanto 1000R UPS On-Line 1000VA 1000W with 8 IEC Outlets

ONLINE UPS Systems XANTO 1000R

  • UPS topology: Double conversion (Online)
  • Output power capacity (VA): 1 kVA
  • Output power: 1000 W
  • AC outlet types: C13 connector
  • Power plug: C14 connector
  • Number of AC...

ONLINE UPS Systems XANTO 1000R

  • UPS topology: Double conversion (Online)
  • Output power capacity (VA): 1 kVA
  • Output power: 1000 W
  • AC outlet types: C13 connector
  • Power plug: C14 connector
  • Number of AC outlets: 8 AC output(s)
  • Battery capacity: 9 Ah
  • Battery voltage: 12 V
  • Typical backup time at full load: 11 minutes
  • Form factor: Rack/Tower
  • Product color: Black
  • ...
See full description See full description

  • Size

    Rack

    UPS designed to be installed in racks (rackmount), that is, in rack cabinets in data centers or server rooms. They have a slim and horizontal shape for space saving.

  • AC Outlets

    The AC outlets are the power output sockets where you connect the devices you want to protect and supply with power through the UPS.

  • Type

    (VFI) On-Line/Double Conversion

    They filter the current coming from the socket and store it in the battery/batteries, while the devices are exclusively powered by the battery/batteries. They offer maximum protection against voltage fluctuations and power outages. They are recommended for sensitive devices and equipment.

  • Plug Type

    IEC

    (C13): Standard computer socket, common in UPS and servers.

  • Power (Watt)

    Indicates the actual power that the UPS can provide to devices. It is expressed in Watts (W) and is the most reliable indicator to know how much load (e.g. PC, monitors, router) it can support.
  • See all
Review the product
Product report

Description

Description

ONLINE UPS Systems XANTO 1000R

  • UPS topology: Double conversion (Online)
  • Output power capacity (VA): 1 kVA
  • Output power: 1000 W
  • AC outlet types: C13 connector
  • Power plug: C14 connector
  • Number of AC outlets: 8 AC output(s)
  • Battery capacity: 9 Ah
  • Battery voltage: 12 V
  • Typical backup time at full load: 11 minutes
  • Form factor: Rack/Tower
  • Product color: Black
  • Rack capacity: 2U
  • Width: 438 mm
  • Depth: 412 mm
  • Height: 88 mm
  • Input operating voltage (min): 110V
  • Input operating voltage (max): 300V
  • Input frequency: 50/60Hz
  • Output operating voltage (min): 208V
  • Output operating voltage (max): 240V
  • Output frequency: 50/60Hz
  • Maximum current: 7.7A
  • Efficiency: 97%
  • Emergency power off (EPO): YES
  • Noise level: 50dB
  • Surge protection features: Fax, Modem, Network
  • Audible alarms: YES
  • Management protocols: SNMP
  • Audible alarm functions: Low battery alarm, Overload alarm
  • USB port: YES
  • Number of USB 2.0 ports: 1
  • Serial interface: YES
  • SCSI interface: RS-232
  • Serial communication ports: 1
  • RS-232 port: 1
  • Number of supported batteries: 3
  • Typical backup time at half load: 27 minutes
  • Battery recharge capability: 4h
  • Cold start: YES
  • Cooling type: Active
  • Display type: LCD
  • International Protection (IP) code: IP20
  • MTBF rate: 50000h
  • Certifications: ISV VFI-SS-111 (EN62040-3), EN62040-1, EN62040-2, CE
  • Operating temperature range: 0 - 40°C
  • Operating humidity range: 20 - 90%
  • Weight: 14100g
  • Packaging type: Box
  • Cables included: Power load cable, USB cable
  • Harmonized System (HS) code: 85078000

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
(VFI) On-Line/Double Conversion

Type

(VFI) On-Line/Double Conversion
They filter the current coming from the socket and store it in the battery/batteries, while the devices are exclusively powered by the battery/batteries. They offer maximum protection against voltage fluctuations and power outages. They are recommended for sensitive devices and equipment.
Power (VA)
1000 VA

Power (VA)

Indicates the maximum electrical load that the UPS can support and is measured in Volt-Amperes (VA). It is the apparent power of the UPS and is used to compare the size/category of UPS units.

Note: VA is not the actual power that devices can consume. To determine what you can connect, always check the Power (W) as well.

Usage Examples:

  • 800VA 480–560 W Router, modem, small computer, LED lighting
  • 1000VA 600–700 W Office PC with monitor, small printer, NAS
  • 1500VA 900–1050 W Powerful PC or gaming, multiple office devices
  • 2000VA 1200–1400 W Workstation, small server, cash register + POS
  • 3000VA 1800–2100 W Server, rack equipment, professional labs, studio
Power (Watt)
1000 W

Power (Watt)

Indicates the actual power that the UPS can provide to devices. It is expressed in Watts (W) and is the most reliable indicator to know how much load (e.g. PC, monitors, router) it can support.
Size
Rack

Size

Rack
UPS designed to be installed in racks (rackmount), that is, in rack cabinets in data centers or server rooms. They have a slim and horizontal shape for space saving.
Output Waveform
Pure Sine Wave

Output Waveform

Pure Sine Wave
They are ideal for the efficient operation of sensitive and important machines such as hospital equipment, servers, telecommunications, and laboratory components. It is recommended to use them in machines that have Active PFC power supplies.
Battery Duration (Full Load)
11 min
Noise Level
50 dB
Display Screen
Digital Display

Connectivity

USB
Yes
AC outlets
8

AC outlets

The AC outlets are the power output sockets where you connect the devices you want to protect and supply with power through the UPS.
Plug Type
IEC

Plug Type

IEC
(C13): Standard computer socket, common in UPS and servers.
Extra Ports
RJ-11, RJ-45

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
