Radial PZ-DI Active 1 Channel DI Box with Phantom Power
DI Boxes

Radial PZ-DI Active 1 Channel DI Box with Phantom Power Code: R800 3005 00

  • For use with piezoelectric pickups for orchestra instruments, acoustic guitar, acoustic bass
  • 48 V Phantom power
  • Jack IN/Out
  • XLR output
  • 15 dB Pad switch
  • 180° phase switch
  • Ground/lift switch
  • Adjustable low cut...
  • For use with piezoelectric pickups for orchestra instruments, acoustic guitar, acoustic bass
  • 48 V Phantom power
  • Jack IN/Out
  • XLR output
  • 15 dB Pad switch
  • 180° phase switch
  • Ground/lift switch
  • Adjustable low cut
  • High Cut switch 3 kHz
  • Adjustable impedance for piezoelectric and magnetic pickups
  • Metal housing


See full description
Review the product
Product report

Description

Description

  • For use with piezoelectric pickups for orchestra instruments, acoustic guitar, acoustic bass
  • 48 V Phantom power
  • Jack IN/Out
  • XLR output
  • 15 dB Pad switch
  • 180° phase switch
  • Ground/lift switch
  • Adjustable low cut
  • High Cut switch 3 kHz
  • Adjustable impedance for piezoelectric and magnetic pickups
  • Metal housing


Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
R800 3005 00

Technical Specifications

Type
Active
Freequency Range
20 - 20000 Hz
Channels
1
Input Impendance
1000000 ohm
Output Impendance
200 ohm

Power Source

Phantom Power
Yes
Battery
No
Drift
No

Switches

Ground/Lift
Yes
Pad
Yes
Phase
No

Connections

3.5mm Jack Input
No
6.3mm Jack Input
Yes
Stereo RCA Input
No
Balanced XLR Input
No
Unbalanced XLR Input
No
Balanced XLR Output
Yes
Unbalanced Jack Output
Yes

Dimensions

Length
127 mm
Width
84 mm
Height
48 mm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

  • For use with piezoelectric pickups for orchestra instruments, acoustic guitar, acoustic bass
  • 48 V Phantom power
  • Jack IN/Out
  • XLR output
  • 15 dB Pad switch
  • 180° phase switch
  • Ground/lift switch
  • Adjustable low cut
  • High Cut switch 3 kHz
  • Adjustable impedance for piezoelectric and magnetic pickups
  • Metal housing


Manufacturer

Manufacturer Details

Warnings & Safety Information
Product Number
R800 3005 00

Technical Specifications

Type
Active
Freequency Range
20 - 20000 Hz
Channels
1
Input Impendance
1000000 ohm
Output Impendance
200 ohm

Power Source

Phantom Power
Yes
Battery
No
Drift
No

Switches

Ground/Lift
Yes
Pad
Yes
Phase
No

Connections

3.5mm Jack Input
No
6.3mm Jack Input
Yes
Stereo RCA Input
No
Balanced XLR Input
No
Unbalanced XLR Input
No
Balanced XLR Output
Yes
Unbalanced Jack Output
Yes

Dimensions

Length
127 mm
Width
84 mm
Height
48 mm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
