DESCRIPTION

• Comfort of hot water usage
• Compatible with BCH storage and ideal for external hot water storage.
• Easy to install with optional hydraulic connections.

Heating comfort

• 4 stars for combustion efficiency according to EN 92/42 standard.
• Wide modulation range, from 10% to 100% of maximum power.
• New analog pump for improved acoustic comfort and reduced energy consumption.
• Designed for integration with heating system with EBUS2 (solar, hydraulic devices, analog control accessories).
• Analog full premix burner and stainless steel heat exchanger.
• SRA function allows automatic system adjustment to achieve optimal heating operation under all environmental conditions.
• Backlit LCD screen displaying history, operating modes, and temperatures, self-diagnosis.

Usage and installation comfort

• Integration with Control Expert: new and intuitive climate regulation for managing 3 circuits based on space and/or external temperature for greater comfort and energy savings.
• New and intuitive electrical wiring.
• Easier commissioning: automatic deaeration function and combustion adjustment with direct access.
• Simplified maintenance: front access to all components.

Energy saving and environmental respect

• Up to 23% energy savings thanks to connection with Easy Control and SRA function.
• Energy savings up to 35% thanks to connection with Easy Control and SRA function, external sensor, and radiation panels.

Device Type

• Condensing
• Fuel: Natural Gas
• Max. & Min. useful heating power 80/60°C (kW): 12.8~3.2
• Max. & Min. useful heating power 50/30°C (kW): 12.8~3.2
• Efficiency at Nom. load 80/60Hi: (%): 97.6
• Efficiency at Nom. load 30/50Hi: (%): 106.6
• Maximum/Minimum heating temperature (°C): 82~35
• Maximum circuit pressure (bar): 3
• Analog burner adjustment (inverter): 10% ~ 100%
• Heating circulator: Inverter
• Expansion tank capacity (Lt.): 8
• Electrical circuit protection degree: X5D
• Dimensions (WxHxD) (mm): 440x745x388
• Power supply (Ph-Volt-Hz): 1-220~240V-50
• Weight (Kg): 32.00
